TECHNICAL SPECIFICATIONS
|
|
FixedBase Mobile |
Robotics |
Physical
|
| Platform |
Mild Steel |
N.A. |
| Scan Unit (LxWxH) |
1360x760x100mm(4.5×2.5×0.3ft) |
690x650x100mm(2.3×2.1×0.3ft) |
| Scane Unit Weight |
12kg (26 pounds) |
25kg (55 pounds) |
| Power Supply |
110/220VAC; 20A |
14.4VDC; 13A |
| Rechargeable Battery |
N.A. |
NMH (2hours) |
Techonolty
|
| Scan |
Area scan technology |
|
| Video Output Format |
Monochrome/Colour |
|
| Operating System |
Windows 7 |
Robotics |
| Database |
Microsoft SQL |
|
| Intelligent Software |
Automated abnormality detection |
N.A. |
| Scan Time |
< 3 seconds |
<25 seconds |
User Interface
|
| Computer |
Intel-based processor |
|
| Computer Weight |
12kg |
2kg |
| Display |
19″ LCD (touch scree option) |
14″ LCD (Laptop) |
| Image |
Template and real-time images |
Real-time image |
| Visual Verification |
16xdigital synchronised zoom |
16xdigital zoom |
| Alert Types |
Audio and visual |
N.A. |
| Wireless Communication |
N.A. |
50 m 2.4 GHz Wifi |
Environmental
|
| Operating Temperature |
-20ºC to 70ºC |
0ºC to 60ºC |
| Humidity |
20% to 95% non-Condensing |
|
| Scan Unit Rating |
FCC; CE; IP65 |
N.A. |
Optional Features
|
| Licence plate recognition |
Reports LPR results with image captured |
N.A. |
| (LPR) |
Camera TypeExport Video Stream : Analog/Digital: Analog |
|
